Canon Cinema EOS C500 Mark II 5.9K Full-Frame Camera Body (EF Mount)

Customizable full frame cinema camera that’s built for creative freedom

Key Features

  • Full-Frame CMOS Sensor, DIG!C DV 7 Chip
  • Full-Frame, Super 35, and Super 16 Modes
  • DCI 4K/2K, UHD 4K, and HD Modes
  • User-Changeable Lens Mounts

Canon Cinema EOS C500 Mark II

Impressive usability and imaging power combine in the EOS C500 Mark II, the customizable full frame cinema camera that’s built for creative freedom. Discover Canon EOS C500 Mark II, the new generation cinema EOS system euipped with a 5.9K full frame sensor. Visit UBMS Dubai showroom to get the best price.

The lightweight body comes equipped with Canon's 5.9K full-frame CMOS sensor capable of over 15 stops of dynamic range. The newly developed DIGIC DV 7 Image Processor expands functionality and flexibility by enabling features such as 5.9K recording, internal recording of Canon Cinema Raw Light and Dual Pixel Autofocus.

Canon Cinema EOS C500 Mark II Manual

The Cinema EOS C500 Mark II is the perfect expression of form and function, exceptionally adaptable to virtually any production with its modular design. Three expansion units and user changeable lens mounts enable operators to build their ideal cinema system.

5.9K Full Frame CMOS Sensor, with support for Super 35mm and Super 16mm crop modes

The Cinema EOS C500 Mark II features Canon’s high-resolution 5.9K (38.1 x 20.1mm) Full Frame CMOS sensor, which offers exceptional low noise and a broad range of tonality with over 15 stops of dynamic range. The sensor’s expansive native cinema gamut goes beyond that of current standards, including ITU-R BT.2020 and DCI-P3, helping the EOS C500 Mark II achieve more natural skin tones and allowing for greater freedom in color grading in both SDR and HDR productions. Buy Cinema EOS C500 Mark II from UBMS Dubai. Canon EOS C500 Mark II Price is very good in UBMS Showroom. Come and experience the Canon EOS C500 Mark II camera at UBMS showroom and get the best price. We can ship Canon EOS C500 Mark II to all GCC countries (Bahrain, Kuwait, Oman, Qatar, Saudi Arabia ) & African Countries .

The Full Frame sensor is capable of capturing footage in a wide variety of aspect formats, including DCI-4K, UHD and Anamorphic Widescreen. The Cinema EOS C500 sensor supports both anamorphic and spherical lenses. In addition to full-frame, the sensor can also be paired with conventional Super 35mm and Super 16mm lenses using appropriate sensor crop modes, lens mount and adapter. To know more about EOS C500 Mark II contact UBMS.

The EOS C500 Mark II features a newly developed DIGIC DV 7 image processor which enables Cinema RAW Light recording internally at 5.9K, as well as supporting recording of Canon’s XF-AVC format in 4K 4:2:2 10-bit. Simultaneous recording of the same file format is possible to the dual CFexpress card slots, with an additional SD card slot for proxy files

The EOS C500 Mark II uses a high-quality debayering algorithm when over sampling 5.9K for 4K/UHD recording. This suppresses moiré and reduces noise, resulting in a superior quality image.

User Changeable Lens Mounts which gives users freedom to use the lenses they desire

User interchangeable lens mounts and an available B4 mount adapter gives operators the freedom to make bold creative choices based on the subject matter.

The EOS C500 Mark II ships with an EF Mount that can be user swapped to an optional Locking EF (EF-C) or PL mount. Each mount swaps easily by simply removing four M3 hex screws. A shim set is provided with each mount kit in order to adjust back focus for the precision in focusing accuracy that professionals rely

Newly developed DIGIC DV 7 Image Processor, which powerfully processes high-resolution image data The EOS C500 Mark II uses a newly developed DIGIC DV 7 Image Processor that takes the extensive RAW information captured from the 5.9K imaging sensor and processes it for output. DiG!C is also the engine behind features such as high frame rate recording, Dual Pixel Auto Focus, Cinema Raw Light Recording, HDR(PQ and HLG) output, electronic image stabilization, proxy recording and oversampling 5.9K processing.

Canon Cinema RAW Light and XF-AVC Recording

Thanks to the powerful DIGIC DV 7 image processing platform, the EOS C500 Mark II can record Cinema RAW Light directly to onboard CFexpress cards, which keeps the data-rich signal captured by the 5.9K full-frame sensor intact. Cinema RAW Light offers plenty of freedom for grading in file sizes that are about 1/3 to 1/5 the size of Cinema RAW, offering a great combination in terms of codec efficiency and quality.

When recording in 5.9K Cinema RAW Light, 60 fps is available, which is an ideal range of high-quality slow-motion capture for typical human movements. In 2K (Crop) mode, frame rates up to 120fps are available allowing users to slow down the action even further, for more dramatic scenes and special effects. Two new buttons S&F(Slow and Fast Motion) and S&F FPS (Slow and Fast Motion – Frames per Second) have been added to gives quick access to desired speed settings, making it simple to utilize this creative tool quickly and spontaneously when the moment is right.

To accurately record the extensive data produced by the 5.9K imaging sensor and provide greater recording times, the EOS C500 Mark features two CFexpress recording slots. CFexpress is the future of onboard recording media providing write speeds needed for higher resolutions and frame rates. The dual card slots can be used to either create an instantaneous backup thorough simultaneous recording or extend record run times by relay recording.

Proxy Recording

Higher resolution, greater bit depths and faster frame rates provide versatility and greater image quality but come at the cost of much larger file sizes. Proxy files can greatly speed up the editorial process by providing a lower bandwidth alternative for the initial file sharing and edits.

Canon’s powerful, high-speed DIGIC DV 7 image processor makes it possible for the EOS C500 Mark II to simultaneously record 2K Proxy files. Cinema RAW Light (5.9K, 4K Crop, or 2K (Crop)) can be recorded to the internal CFexpress card while an XF-AVC 2K 4:2:0 8-bit Proxy can be recorded directly to an internal SD card.

Compatibility with EF and PL Lenses*

With optional mount kits, users can swap from EF to Locking EF-C or PL mounts on their own. PL lenses are a cinema legacy. With a wide breath of options available to cinematographers choosing a lens is an important part of the creative process. The EOS C500 Mark II’s interchangeability now makes it possible to take any PL lens and pair it with Canon’s state-of-the-art sensor to meet the needs of any project.

Using Canon’s EF still lenses offer remarkable new possibilities for cinematographers including the use of specialty lenses like the fisheye zoom, tilt-shift and super-telephotos.

The amount of viable lens options can be further increased through an optional B4 lens mount adapter. This adapter is available for the PL or EF mount allowing 2/3” lensing options to be used with the camera.

Anamorphic Lens Support

The EOS C500 Mark II offers cinematographers anamorphic lens support. Users can now achieve wide cinematic looks and oval bokeh particular to anamorphic glass. It is a distinctly cinematic palette that is within reach for your next project.

Electronic Image Stabilization

The EOS C500 Mark II is the first Canon Cinema EOS camera to feature built-in five-axis electronic IS that works with almost any lens including anamorphic.

Modular Design with three available Expansion Units allows a high level of connectivity and interoperability

A new modular design allows productions to optimize and customize the EOS C500 Mark II to specific shooting needs. Accessories and expansion units can be easily attached to provide different levels of functionality. The camera is equally at home fully rigged with a large zoom lens, FIZ unit, audio accessories and rangefinder as it is stripped down flying on a drone.

Support for Custom User LUTs

Users can upload and apply custom LUTs to the EOS C500 Mark II. LUTs can be assigned to specific output terminals and the LCD or viewfinder. Clients can be viewing one LUT, while production works from another, giving different production roles the ability to customize the look of the image to their needs.

4 Channel Audio Recording

With Expansion Unit EU-V2, the EOS C500 Mark II supports up to 4-channel audio recording. Audio input from the camera’s internal microphone, mini mic port, and XLR ports can be assigned to the 4 different audio channels. This flexibility allows a wide range of audio devices to be connected and mixed directly on the camera.

Image Sensor
Image Sensor Size
Full-Frame
Sensor Type
CMOS
Sensor Resolution
Actual: 6062 x 3432 (20.8 MP)
Resolution Modes
5952 x 3140 in 17:9 and Recording in DCI 4K, DCI 2K
5580 x 3140 in 16:9 and Recording in UHD 4K, 1080p
Color Filter
Bayer
ISO
160 to 25,600 (Native)
100 to 102,400 (Expanded)
Camera
Lens Mount
Canon EF
Lens Communication
Yes, with Autofocus Support
Interchangeable Lens Mount
Yes
Internal Filter Holder
No
Built-In ND Filter
Mechanical Filter Wheel with 2 Stop (1/4), 3 Stop (1/8), 4 Stop (1/16), 6 Stop (1/64), 8 Stop (1/256) ND Filters
Built-In Microphone Type
Mono
Recording Media
2 x CFexpress Card Slots
1 x SD (Unspecified Type) UHS-II Card Slot
Internal Recording
Raw Recording
Cinema RAW Light 10-Bit, 12-Bit:
5952 x 3140 at 23.98/24/25/29.97/50/59.94 fps
4096 x 2160 at 23.98/24/25/29.97/50/59.94 fps
3840 x 2160 at 23.98/24/25/29.97/50/59.94 fps
Recording Modes
XF-AVC 4:2:2 10-Bit:
4096 x 2160p at 23.98/24/25/29.97/50/59.94 fps (160 to 810 Mb/s)
3840 x 2160p at 23.98/24/25/29.97/50/59.94 fps (160 to 810 Mb/s)
2048 x 1080p up to 120 fps (160 to 810 Mb/s)
1920 x 1080p at 23.98/24/25/29.97/50/59.94 fps (160 to 810 Mb/s)
1920 x 1080p at 50/59.94 fps (160 to 810 Mb/s)
XF-AVC 4:2:0 8-Bit:
2048 x 1080p at 23.98/24/25/29.97/50/59.94 fps (24 to 35 Mb/s)
Gamma Curve
Canon Log 2, Canon Log 3, HDR-HLG, HDR-PQ, Normal 1, Wide DR
Audio Recording
4-Channel 24-Bit 48 kHz LPCM Audio
Interfaces
Video Connectors
1 x BNC (12G-SDI) Output
1 x HDMI Output
Audio Connectors
1 x 1/8" / 3.5 mm Stereo Mic Level Input
2 x 3-Pin XLR Mic/Line Level Input
1 x 1/8" / 3.5 mm Stereo Headphone Output
Other I/O
1 x BNC Timecode
Display
Display Type
LCD
Screen Size
4.3"
Touchscreen
Yes
Screen Resolution
2,760,000 Dots
EVF
EVF
Optional, Not Included
Power
Battery Type
Canon BP-A Series
General
Dimensions
6.6 x 6 x 5.8" / 16.76 x 15.24 x 14.73 cm
Weight
3.9 lb / 1.77 kg
  • EOS C500 Mark II BODY
  • Measure Hook
  • Camera Grip GR-V1
  • Stopper
  • Thumbrest
  • Microphone Holder Unit
  • LCD Monitor LM-V2LCD Attachment Unit LA-V2
  • Handle Unit
  • Hex Wrench 3/16 E
  • Hex Wrench M4
  • Hex Wrench M3
  • Hex Socket Head Bolt (1/4 inch)
  • Hex Socket Head Bolt (M3)
  • Bolt Stopper
  • SS-1200 Shoulder Strap
  • Battery Charger CG-A20
  • Compact Power Adapter CA-CP200B
  • AC Cable US
  • AC ADAPTER AC-E19
  • Power Cord US
  • BP-A60 JP Battery Pack
  • Extension Unit Attachment Bracket
  • UN-5 Unit Cable
  • CFexpress Card Reader
  • 512GB CFexpress Card
  • 5.9K Full Frame CMOS Sensor, with support for Super 35mm and Super 16mm crop modes
  • User Changeable Lens Mounts which gives users freedom to use the lenses they desire
  • Newly developed DIGIC DV 7 Image Processor, which powerfully processes high-resolution image data
  • Canon Cinema RAW Light and XF-AVC Recording
  • Proxy Recording
  • Compatibility with EF and PL Lenses
  • Anamorphic Lens Support
  • Electronic Image Stabilization
