Sonifex AVN-PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal
Sonifex AVN-PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal
Sonifex AVN-PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal
Sonifex AVN-PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal

Sonifex AVN-PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal

بائع: Sonifex
رمز التخزين التعريفي: AVN-PM8
التوفر: New Release - Preorder
AED 14,000.00 AED 14,700.00 Incl. VAT
AED 14,000.00 AED 14,700.00 Incl. VAT
AED

Key Features:

  • Eight balanced mic/line inputs with adjustable gain and +48 V phantom power
  • Eight balanced stereo line outputs via D-Sub and StudioHub®-pinout RJ45
  • AES67/RAVENNA audio-over-IP support with mix and route engine
  • Responsive web server for remote configuration and control
  • Dual Gigabit Ethernet and SFP network connectivity
  • Dual AC and DC redundant power inputs
  • 10 user-assignable GPIO ports and relay output

ًالشحن مجانا

شحن قياسي مجاني للطلبات التي تزيد عن 500 درهم إماراتي

التبادلات والإرجاع

يُمكن استبدال المنتج أو إرجاعه خلال خمسة (5) أيام فقط من تاريخ الشراء. تعرّف على المزيد.


Buy with 0% installments and pay AED 1166.67 for 12 months with selected banks. Read More
وصف
وصف
x

The Sonifex AVN‑PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal is a professional audio mix engine and network interface designed for flexible routing, mixing, and distribution in RAVENNA/AES67 audio-over-IP environments. It offers eight balanced XLR mic/line inputs with adjustable gain and +48 V phantom power for each channel, plus eight balanced stereo line outputs accessible via D-Sub and StudioHub®-pinout RJ45 connectors, making it ideal for broadcast, live production, and installation workflows.

Equipped with a responsive web server for remote control and configuration, the AVN‑PM8 allows any physical input or AoIP stream to be freely mixed and routed to any physical output or AES67 stream. It supports up to eight AoIP input streams (up to 16 channels) and up to eight AoIP output streams (up to 64 channels), enabling versatile applications such as stereo clean-feed generation, IFB distribution, zone mixing, and headphone systems. Dual Gigabit Ethernet ports and an SFP port provide flexible network connectivity, while dual AC and DC power inputs ensure reliable redundant operation.

ID: 50552681070878

اقرأ المزيد
Reviews
Reviews
x

UBMS is an authorized distributor of Sonifex in Dubai, Abu Dhabi, UAE. Contact us or buy online Sonifex AVN-PM8 8 Mic/Line Inputs, 8 Line Outputs, Terminal Block, AES67 Portal with best price.
